20ft Expandable Foldable Container Shelter Portable Modular Shelter

20ft Expandable Foldable Container Shelter Portable Modular Shelter

1. Brief introduction:

Our 20ft Container Shelter is a newly upgraded modular portable building, perfectly combining foldable and expandable functions. As a professional Expandable Container Shelter and Foldable Container Shelter, it solves the high transportation cost and inconvenient movement problems of traditional container houses. With flexible expansion structure, full insulation configuration and complete indoor living facilities, this multi-functional Container Shelter is the ideal temporary space solution for global commercial, construction, residential and emergency scenarios.

Folded into standard container size for sea and land transportation, the shelter allows 2 units loaded in one 40FT HQ container, greatly cutting logistics expenses. After simple on-site expansion, it forms a 34.77 square meters independent living space with complete 2-bedroom, 1-living room, 1-kitchen and 1-bathroom layout, realizing quick installation and immediate occupancy.

2.  Core Features & Advantages

2.1 Foldable & Expandable Space Design

This 20ft Container Shelter adopts double-wing expandable structure. The folded dimension is only 5.9m × 2.2m × 2.48m, which is convenient for container shipping and truck transportation. After expansion, the width is increased to 6.3m, providing a spacious 34.77㎡ usable area. The internal size of 5.7m × 6.1m × 2.28m ensures comfortable living and working space, balancing transportation economy and usage practicality.

2.2 Insulated-temp; Weather-Resistant Structure

The exterior wall adopts durable metal carved panels with anti-corrosion, waterproof and UV-resistant performance, adapting to all-weather outdoor use. The interior walls and roof are made of high-density EPS insulated composite panels, which effectively isolate high and low temperatures, maintain constant indoor temperature, and provide excellent thermal insulation, heat preservation and sound insulation effects. It can be used stably in tropical, temperate and cold regions all year round.

2.3 Complete Turnkey Living Configuration

Different from ordinary simple shelters, our Expandable Container Shelter is fully prefabricated with complete supporting facilities. Equipped with L-shaped kitchen cabinets, upper hanging cabinets and double water sink, it meets daily cooking needs. Standard PVC doors and windows ensure lighting and air circulation. The integrated independent bathroom is equipped with basin, mirror cabinet, toilet, shower system and bathroom heater, with UV moisture-proof board overall protection. The multi-type floor materials are used in different areas to ensure wear resistance, waterproof and skid resistance, realizing one-stop occupancy without secondary decoration.



2.4 Lightweight & Easy Installation

The whole unit weighs only about 3.8 tons, with optimized structural design, strong and stable, not easy to deform. No complicated foundation and welding construction is required on site. A small number of workers can complete unfolding, fixing and installation in a short time, greatly saving construction time and labor cost. The foldable structure also supports repeated disassembly, movement and reuse, with super high cost performance.



2.5 Wide Application Scenarios

This Foldable Container Shelter is widely applicable for construction site offices and worker dormitories, outdoor engineering temporary rooms, disaster relief emergency shelters, field operation rooms, scenic spot glamping container houses, rural temporary houses, mining area accommodation and other scenarios. It can be used for both short-term emergency use and long-term fixed residence.

3. Technical Specifications

Parameter Item	Specific Details
Expanded Dimensions	5.9m × 6.3m × 2.48m
Folded Dimensions	5.9m × 2.2m × 2.48m
Internal Dimensions	5.7m × 6.1m × 2.28m
Unit Weight	Approx. 3.8 Tons
Floor Area	34.77 m²
Shipping Capacity	2 Units / 40FT HQ Container
House Layout	2 Bedrooms + 1 Living Room + 1 Kitchen + 1 Bathroom
Exterior Wall Material	Metal Carved Panel
Interior & Roof Material	EPS Insulated Composite Panel
Floor Material	Main box: Cement fiber board + vinyl flooringSide wing: Cement fiber board + bamboo plywoodBathroom: Cement fiber board + waterproof vinyl flooring
Standard Configuration	L-shaped cabinet & upper cabinet, double water sink, PVC door & window, integrated bathroom basin, mirror cabinet, toilet, shower, bathroom heater, UV moisture-proof board

4.  Why Choose Our Container Shelter

We focus on the R&D and production of high-quality 20ft Container Shelter, Expandable Container Shelter and Foldable Container Shelter. Compared with traditional prefab houses, our products have more flexible structure, lower transportation cost, faster installation speed and more complete supporting facilities. Strict material selection and standardized production ensure stable product quality and long service life. We support customized size, color and configuration to meet different customer project needs, providing one-stop modular space solutions for global clients.
